Golden Choice GC-M5 Auto-Flipping Tape edge Machine

GC-M5

Delivery

FOB

minimum order

1 set

Supply Ability

100set / Month

Country of Origin

NINGBO PORT

Quantity

Contact Now

add to cart

Main application and performance:

By using the structure of moving mattress and fixing sewing head, model GC-M5 tape edge closing machine is an ideal mate equipment for automatic product line of mattress production, it could make the mattress move in or move out, corner and flip automatically; its unique abilities such as sewing head auto raising or lowering at the corner, speed auto slowdown at corner, sewing speed auto recovery after passing corner, adjustable sewing head tilting angle, adjustable sewing head lift, adjustable sewing speed, and adjustable conveyer speed, greatly increases the sewing quality.

Technical data:

Sewing head type:	chain stitch
Sewing head lifting range:	0 - 240mm
Tilting angle of Sewing head:	25 - 65
Table conveyer belt speed:	10 - 14m/min
Available mattress thickness:	50 - 400mm
Sewing head speed:	1642-2740r/min
Production efficiency:	16 - 20 units/hour
Motor power:	3.2 KW
Air pressure:	0.6 - 0.8Mpa
Work table size:	L3750xW1980 mm

item	Value
Applicable Industries	Garment Shopa,Machinery Repair Shops,Retall
After warranty Service	After warranty Service
Local Service Location	Egypt,Brazil,Saudi,Arabia,Pakistan.Morocco,Argentina
Showroom Location	Egypt,Brazil,Saudi,Arabia,Pakistan.Morocco,Argentina
Condition	New
Place of Origin	China Zhejian
Brand Name	Choice
Feed Mechanism	Manual
Certification	CE
Warranty	1 Year
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Marketing Type	New Product 2023
Warranty of core components	1 Year
Voltage	110V/220V
OEM	Avaliable
